BFT Virgo Smart BT A20 articulated arm gate motor Oman
BFT Swing Gate Motors

BFT Virgo Smart BT A20 Swing Gate Motor in Oman | 24V, 200 kg

In stockSKU P930129-00002

A 24 V articulated arm operator for swing leaves up to 2 m and 200 kg, with the THALIA board built in and U-Link ready. Built for wide pillars a ram cannot reach, not just light gates. This is the Master unit — a two-leaf gate needs one of these plus a Slave motor, not two Masters. Self-locking, so no electric lock is needed. Fitted across the Sultanate.

Price
Original price was: 355 OMR.Current price is: 353 OMR.

Availability: 10 in stock

Open every day, 8:00 am to 10:00 pm

  • Authorized dealerOfficial brand distribution
  • Supply and installationOur own technicians across Oman
  • Manufacturer warrantyClaims handled locally in Oman

Overview

The BFT Virgo Smart BT A20 is a 24 V articulated arm operator. It takes swing leaves up to 2 m and 200 kg. The THALIA control board is built into the housing, and it opens 120 degrees in 14 seconds. We fit the BFT Virgo Smart BT A20 Oman kit across the Sultanate.

One motor drives one leaf. A pair needs a Master and a Slave

This unit is the Master. Its THALIA board controls the motor inside it. It can also drive a second leaf, but only if that second motor is on site.

UnitBFT codeHas a board?
Virgo Smart BT A20 (Master)P930129 00002Yes, THALIA built in
Virgo Smart BT A20 SlaveP930130 00002No, runs from the Master

A two-leaf gate is one Master and one Slave, not two Masters. Order two of this listing and the second board goes to waste. Tell us the number of leaves before we quote.

BFT Virgo Smart BT A20 Oman specifications

Max leaf width2 m
Max leaf weight200 kg
Motor voltage24 V
Board supply230 V
Power110 W
Control unitTHALIA, built in
Limit switchElectromechanical
Maximum angle120 degrees
Time to open14 seconds
LockingMechanical, irreversible
ReleasePersonal key
DutySemi-intensive
ProtectionIP44, -20 to 55 degrees

Built for pillars, not just weight

200 kg is not the reason to choose this motor. Pillar depth is.

The articulated arm folds around a wide pillar that a straight ram cannot reach past. BFT rates it to a hinge-to-pillar-edge distance of roughly 235 mm. That is well beyond a ram like our ATHOS AC A25. If your gate is heavier, the wide-pillar answer is our IGEA BT instead.

Common questions about the BFT Virgo Smart BT A20 Oman kit

How often can it run?

BFT rates it semi-intensive, around 60 cycles a day. That suits a villa or apartment entrance, not a busy public gate.

Can someone push my gate open?

No. The gearbox is self-locking once closed. No electric lock is needed.

Does it come with U-Link?

Yes, through the THALIA board. On a single gate you may never use it. Linked to other BFT units on the same site, it lets one system manage several entrances.

My pillar is narrow, not wide. Is this still right?

Probably not. Narrow pillars from about 80 mm suit our E5 BT A18 better. Measure your pillar and we will confirm.

Technical data

Product Specifications

BFT Virgo Smart BT A20 Specifications

  • Brand: BFT
  • Model: Virgo Smart BT A20 (Master)
  • Product code: P930129 00002
  • Slave unit code: P930130 00002 — required for a two-leaf gate
  • Operator type: Articulated arm
  • Max. leaf width: 2 m
  • Max. leaf weight: 200 kg
  • Hinge to pillar clearance: up to approx. 235 mm
  • Motor voltage: 24 V
  • Board power supply: 230 V
  • Power consumption: 110 W
  • Control unit: THALIA, integrated
  • Limit switch type: Electromechanical
  • Maximum opening angle: 120°
  • Time to open: 14 s
  • Impact reaction: Electronic torque limiter
  • Locking: Mechanical — self-locking, no electric lock required
  • Release: Personal key
  • Frequency of use: Semi-intensive, approx. 60 cycles/day
  • Interconnectivity: U-Link
  • Protection rating: IP44
  • Operating temperature: -20 °C to +55 °C
  • Made in: Italy
